Cx Series Operator’s Manual Drill - 67
Operate
Remove Rod
If the length of rod outside the bore reaches 30’ (9m), or as required by space, use a Helper to remove rod
sections as needed.
Remove Rod Section
1. Stop rotation of drilling attachment.
2. Disconnect and remove first rod. Special tool (p/n 351-272) may be used. See “Disassemble Drill
String” on page 68.
Reconnect Drill String
1. Slowly move machine forward until rod section and drilling attachment are about 1” (2.5cm) apart.
2. Have Helper lightly hold new rod section.
3. Rotate drilling attachment to align slip latches of new rod section and drilling attachment if needed.
4. Move machine forward slowly. As soon as new rod section engages drilling attachment, have Helper
move hands clear.
5. Slightly move forward until slip latch connection is correctly latched.
Rotating shaft. Crushing will cause death or serious
injury. Stay away.
To help avoid injury: Only access drilling attachment once rotation has
fully stopped.
Pinch point. Crushing will cause serious injury. Stay away.
To help avoid injury:
• Keep hands at least 6” (15cm) from ends of rod.
• Support rods from underneath with open palms. Never grip rods.
