Controls - 24 XT1600 Operator’s Manual
Front Console
CMW
3. Tachometer Displays engine RPM x 100.
4. Fuel gauge Displays fuel level in tank. Use only #2 diesel fuel.
Tank holds 20 gal (75.7 L).
5. Engine coolant
temperature indicator
Lights when coolant
temperature exceeds 230°F
(110°C).
6. Hydraulic fluid
temperature indicator
Lights when hydraulic fluid is
over 210°F (100°C).
• Allow engine to cool.
• Check hydraulic fluid level.
Item Description Notes
c00ic120h.eps
