Transport - 50 XT1600 Operator’s Manual
Lift
CMW
Lift
Points
Lifting points are identified by lifting decals. Lifting at other points is unsafe
and can damage machinery.
Procedure
Use a crane capable of supporting the
equipment's size and weight. See “General
Dimensions” on page 91 or measure and weigh
equipment before lifting.
1. Attach chains to four lift points (two on each
side of unit).
2. Attach each chain securely to cross
members.
3. Bring chains together to a central pull point.
Crushing weight. If load falls or moves it could kill or crush you. Use
proper procedures and equipment or stay away.
IMPORTANT: Length of spreader bars should
be equal to width of unit.
