Service - 86 XT1600 Operator’s Manual
250 Hour
CMW
Check Planetary Gearbox Oil Level
Check planetary gearbox oil level every 50 hours.
Position one plug level with center of track and
the other at the bottom as shown. Oil level should
be visible at fill plug (shown). Add recommended
oil as needed.
Change Hydraulic Filter
Change hydraulic filter every 250 hours. Remove
floor panel to access filter (shown.)
IMPORTANT: Oil goes in very slowly so wait a
few seconds and recheck level before
installing plug.
