Service - 88 XT1600 Operator’s Manual
2000 Hour
CMW
Change Planetary Gearbox Oil
Change planetary gearbox oil every 1000 hours.
To change
1. Position one plug level with center of track
and the other at the bottom as shown.
2. Remove plugs (1, 2) and drain oil.
3. Install drain plug (2).
4. Add approximately 25 oz (740 mL) of
recommended oil at fill plug (1) or until visible
at plug.
5. Install fill plug (1).
2000 Hour
Change Engine Coolant
Drain cooling system at drain (2). Refill (1) with
approved coolant every two years or 2000 hours.
IMPORTANT: Oil goes in very slowly so
wait a few seconds and recheck level
before installing plug.
NOTICE:
• The use of non-approved coolant may
lead to engine damage or premature
engine failure and will void engine
warranty.
• See “Approved Coolant” on page 76.
for list of approved coolants.
