Drive - 48 XT855 Operator’s Manual
Steer
CMW
Steer
To steer while moving forward, push left joystick forward and then move to left or right. Unit will gradually
turn to left or right.
To steer while moving backward, pull left joystick back and then move to left or right. Unit will gradually
turn to left or right.
For tight steering in low speed, move left joystick to center position and then to left or right side. Tracks
will counter-rotate and turn unit in a tight circle.
Shut Down
1. Move all controls to neutral position.
2. Ensure lift arms are lowered to ground and ensure excavator is in the stow position. See “Stowing the
Excavator” on page 47.
3. Run engine at low idle for three minutes to cool.
4. Turn ignition switch to STOP.
5. Remove key.
NOTICE: When driving unit more than a few feet (meters), pivot seat so that operator is facing lift arms.
If operator is facing excavator, operation of track drive controls is reversed.
NOTICE: Unit should not be parked on a slope unless chocked or blocked.
