Dig - 64 XT855 Operator’s Manual
Setup
CMW
Dumping Bucket
Use right and left joysticks to control excavator dipper, boom, and bucket.
1. Position unit.
2. Fill bucket.
3. Dump bucket.
4. Continue filling and dumping buckets.
5. Reposition unit as needed to complete job.
6. When job is finished, stow excavator, pivot seat to face tool carrier end, switch unit into tool carrier
mode and drive away from area.
Onto truck Into hole or onto ground
Position unit between material to be loaded and
back end of truck, if possible.
Position unit to minimize the need for travel.
Onto truck Into hole or onto ground
• Swing boom into position over truck.
• Raise boom above truck bed.
• Move dipper out and open bucket.
• Swing boom back into position over fill site.
• Swing boom into position over dump site.
• Move dipper out and open bucket.
• Swing boom back into position over fill site.
IMPORTANT: If operator is facing excavator when driving, unit movements are reversed.
