XT855 Operator’s Manual Service - 83
10 Hour
CMW
Check Track Tension
Check track tension every 10 hours. Measure
length of spring as shown. When tracks are
properly tensioned, spring length (A) should be
9 1/2” (241 mm). Adjust as needed (see page 92).
For more information on rubber tracks, see the
publication Rubber Tracks, Types of Damage
During Operation (p/n 053-1056) delivered with
your machine.
