Specifications - 96 XT855 Operator’s Manual
CMW
Tool Carrier Dimensions U.S. Metric
A Operating height with standard bucket, max 104 in 2.6 m
B Hinge pin height, max 83 in 2.1 m
C Dump height with standard bucket, max 69 in 1.75 m
D Bucket rollback angle, top 115° 115°
E Dump angle, standard bucket 25° 25°
F Reach with standard bucket, fully raised 21 in 533 mm
G Bucket rollback angle, ground level 16° 16°
H Reach at grade 34 in 864 mm
Excavator Dimensions U.S. Metric
K Loading height, max 72 in 1.8 m
L Dig depth, max 83 in 2.1 m
M Reach from swing post 103 in 2.6 m
Lift capacity, boom over end and swing arc, SAE
at 48 in (1.2 m) 370 lb 167 kg
at ground level 457 lb 207 kg
at 72 in (1.8 m) 485 lb 220 kg
Lift capacity, dipperstick over end and swing arc, SAE
at 48 in (1.2 m) 566 lb 256 kg
at 72 in (1.8 in) 1392 lb 631 kg
