DITEC CROSS18 User Manual

28
IP1984EEN - 2015-09-22
3. Technical data
Ditec CROSS18 Ditec CROSS18E Ditec CROSS18VE Ditec CROSS19V
Power supply 230 V~ 50 Hz 230 V~ 50 Hz 230 V~ 50 Hz 400 V~ 50 Hz
Absorption 3 A 3 A 3 A 1,2 A
Thrust 1200 N
1200 N
1200 N 1500 N
Door speed 0,2 m/s 0,2 m/s 0,2 m/s 0,2 m/s
Max run 11 m 20 m 20 m 20 m
Max door weight 1800 kg 1800 kg 1800 kg 1800 kg
Service class 4 - INTENSIVE 4 - INTENSIVE 4 - INTENSIVE 4 - INTENSIVE
Min number of
consecutive cycles
50 50 50 50
Intermittence
S2 = 30 min
S3 = 50%
S2 = 30 min
S3 = 50%
S2 = 30 min
S3 = 50%
S2 = 30 min
S3 = 50%
Temperature min -20° C
max +55° C
min -20° C
max +55° C
min -20° C
max +55° C
min -20° C
max +55° C
Degree of protec-
tion
IP24D IP24D IP24D IP24D
Control panel E1A - LOGIC M E1A (incorporated) LOGICM
(incorporated)
E1T
3.1 Operating instructions
Service class: 4 (minimum 100 cycles a day for 10 years or 200 cycles a day for 5 years)
Use: INTENSIVE (For vehicle or pedestrian accesses to large condominiums, industrial or
commercial complexes and parking lots with very frequent use).
- Performance characteristics are to be understood as referring to the recommended weight
(approx. 2/3 of maximum permissible weight). A reduction in performance is to be expected
when the access is made to operate at the maximum permissible weight.
- Service class, running times, and the number of consecutive cycles are to be taken as merely
indicative having been statistically determined under average operating conditions, and are
therefore not necessarily applicable to specific conditions of use. During given time spans
product performance characteristics will be such as not to require any special maintenance.
- The actual performance characteristics of each automatic access may be affected by independent
variables such as friction, balancing and environmental factors, all of which may substantially
alter the performance characteristics of the automatic access or curtail its working life or parts
thereof (including the automatic devices themselves). When setting up, specific local conditions
must be duly borne in mind and the installation adapted accordingly for ensuring maximum
durability and trouble-free operation.
