DITEC E2J User Manual

8
IP1935EN  2010-07-19
Trimmer Description
RF
min max
Power adjustment. Adjusts the voltaJe supplied to the motor.
TR
0 s
3 s
30 s
20 s
10 s
Setting motor 1 (M1) closing delay time. From 0 to 30 s.
When closinJ, motor 1 (M1) arrives after a dela\ set with trimmer TR relative to motor
2 (M2).
When openinJ, motor 2 (M2) starts after a dela\ of 3 s relative to motor 1 (M1).
With TR=MIN the door winJs start simultaneousl\.
NOTE: setting TR=MIN with non-overlapping door wings and setting TR>3 s with
overlapping door wings is recommended.
R1
min Disabled
Obstacle thrust adjustment.
The control panel is eTuipped with a safet\ s\stem that stops motion if an obstacle is
encountered durinJ an openinJ operation and stops or inverts the movement durinJ
a closinJ operation.
R1=MIN Jives maximum obstacle sensitivit\ (minimum thrust).
R1=MAX disables obstacle detection (maximum thrust).
TC
0 s Disabled
120 s
Setting automatic closing time. From 0 to 120 s.
With DIP2A=OFF, once a safet\ switch has been activated, the counter starts as soon
as the safet\ switch is released (for example after passinJ throuJh the photocells),
and lasts for a period of time set with trimmer TC (50%).
With DIP2A=ON, the counter starts when automation is opened and lasts for the entire
duration set with trimmer TC (100%).
NOTE: after the activation of the stop command, once contact 1-9 has closed again,
automatic closing is only enabled after a total, partial or step-by-step opening com-
mand.
TM
10 s 120 s
60 s
Operation time adjustment. From 10 to 120 s.
NOTE: set TM=MAX with limit switches installed.
LED On Flashing
SIG
Transmitter enablinJ/storaJe phase. Reception of a radio transmission.
Cancellation of transmitters in proJress.
BIXMR2 memor\ damaJed.
IN
Receipt of command or chanJe in status of
a dip-switch.
/
11
0-11 limit switch contact is open.
/
12
0-12 limit switch contact is open.
/
SA At least one of the safet\ contacts is open. Operations count performed (onl\ when con-
trol panel is switched on):
each rapid Àash = 1000 operations
each slow Àash = 10000 operations
POWER Power suppl\ on.
/
