DITEC OBBI3BH - OBBI3 BFCH Limit Switch Adjustment

12
IP1639EN • 2012-07-31
6.1 OBBI3BFCH limit switch adjustment
The OBBI3BFCH geared motor is tted with magnetic limit switches. Adjust the limit switches in order to obtain
the correct opening and closing of the automation, as indicated in gure.
dima regolazione finecorsa
limit switch adjusting template
finecorsa di apertura
opening limit switch
finecorsa di chiusura
closing limit switch
nero
black
arancione
orange
nero
black
arancione
orange
