1592022550 Quick reference guide IC100CX GB rel.1.0 03/03/2008 Page 8 di 39
13.9 How to Reset the Alarm Log
1) Enter the function “menu”.
2) Use o or n keys to find “ALOG” label.
3) Push “SET” key.
4) Use o
oo
o or n
nn
n keys to find “ArSt” (Alarm reset) label
on the lower display; the upper display shows “PAS”.
5) Push “SET” key and then enter the password value
using o
oo
o or n
nn
n keys; confirm the value pushing
“SET” key.
6) The ArSt label starts flashing for 5s, to confirm the
alarm logging data is reset.
14. KEYBOARD FUNCTIONS
14.1 How to See the Set Point Value
Push and release the “SET” key.
Lower display shows: “SetC” set point chiller;
“SetH” set point heat pump.
The upper display shows the value.
Note:
SetH is available only if configured for Heat Pump.
14.2 How to Change the Set Point Value
1) Push and hold “SET” key (for about 3
seconds).
2) The setpoint value is flashing.
3) Use o
o o
o and n
nn
n to increase or decrease the
new value.
4) Push and release “SET” key or wait the time-
out to exit the programming.
14.3 How to See the real Set Point
When Energy Saving, Dynamic Set Point or Function For
Units Without Water Storage Tank are enabled is possible
to see the real set point.
When the machine is running:
• push “SET” key once: lower display shows “SetC”
(setpoint chiller) or “SetH” (setpoint heat pump) and
upper display shows the value.
• push “SET” key again:
- when “Energy Saving” is enabled the lower
display shows “SEtS” (Energy saving setpoint)
and upper display shows the value.
- when “Dynamic Set” is enabled, the lower
display shows “SEtd” (dynamic set point) and
upper display shows the value.
- when the function for units without water
storage tank is enabled the lower display
shows “Setr” (real set point) and upper display
shows its value.
- when two function above are both enabled,
the lower display shows “Setr” (real set point)
and upper display shows its value.
15. BLACK OUT
After a black-out:
1. the controller restarts from the pervious status.
2. The defrost cycle is stopped.
3. All the working time delay will be reloaded.
