dixell iCHiLL IC200CX Series User Manual

1592022700 User manual iCHILL 200CX Rel. 1.0 22/04/2009
Pg.8/114
3 IC200 CX TABLE OF THE FEATURES
CHARACTERISTICS IC206CX IC208CX
N° KEYS
6
n n
RELAYS
6
n
8
n
DIGITAL INPUTS
11 Config Config
ANALOG INPUTS
4 NTC – PTC
2 NTC - PTC - 4÷20mA - 0 ÷ 5Volt
Config Config
PROPORTIONAL OUTPUTS
2 configurables (signal 0÷10V) Config Config
2 configurables (signal 0÷10V, PWM) Config Config
SERIAL OUTPUTS
TTL with Mod-BusRtu protocol
n n
Remote Keyboard VICX620 (up to 2 remote
keyboards with probe on board)
n n
POWER SUPPLY
12 Vac/dc (+15%;-10%)
n n
24 Vac/dc (± 10%) Opt Opt
MAIN DISPLAY (UPPER DISPLAY)
± 4 digits with decimal point
n n
SECONDARY DISPLAY (LOWER DISPLAY)
± 4 digits with decimal point
n n
OTHER
Clock on board Opt Opt
Buzzer Opt Opt
 configurable = configurable through parameter
 opt = optional
 n = default
