dji FPV User Manual

DJI FPV
User Manual
40
© 2021 DJI All Rights Reserved.
Controlling the Aircraft
The control sticks control the orientation (pan), forward and backward movement (pitch), altitude (throttle), and left and
right movement (roll) of the aircraft. The control stick mode determines the function of each control stick movement.
There are three programmed modes including Mode 1, Mode 2, and Mode 3. Mode 2 is selected by default and
users can also congure custom modes in the goggles. The gure below explains how to use each control stick
mode, using Mode 2 as an example.
Stick Neutral/Center Point: Control sticks are in the center.
Moving the control stick: Push the control stick away from the center or push the throttle stick away
from the lowest position when using Manual mode.
Right StickLeft Stick
Turn RightTurn Left
UP
Down
RightLeft
UP
Down
Turn RightTurn Left
RightLeft
Forward
Backward
Left Stick Right Stick
Forward
Backward
Right Stick
UP
Down
Forward
Backward
Left Stick
Turn RightTurn Left
RightLeft
Mode 1
Mode
2
Mode
3

dji FPV Specifications

General

Product type	Battery
Compatibility	FPV Drone
Product color	Black
Brand compatibility	DJI
Battery voltage	22.2 V
Battery capacity	2000 mAh
Battery LED indicator	Yes
Minimum operating temperature	5 °C
Quantity per pack	1 pc(s)

Weight and Dimensions

Weight	295 g
