dji FPV - Page 53

DJI FPV
User Manual
53
© 2021 DJI All Rights Reserved.
3. Pry a corner of the top shell from the bottom side of the aircraft.
4. Facing the aircraft, hold the front frame arm and push in the direction shown to remove the top shell.
5. Remove the four M2 screws on the front.
