dji FPV User Manual

DJI FPV
User Manual
63
© 2021 DJI All Rights Reserved.
Charging Temperature Range 41° to 104° F (5° to 40° C)
Max Charging Power 90 W
Goggles
Weight Approx. 420 g (incl. headband and antennas)
Dimensions
184×122×110 mm (excl. antennas)
202×126×110 mm (incl. antennas)
Screen Size 2 inch×2
Screen Resolution
(Single Screen)
1440×810
Screen Refresh Rate 144 Hz
FOV 30° to 54°; Image size: 50-100%
Interpupillary Distance Range 58-70 mm
Operating Frequency 2.400-2.4835 GHz; 5.725-5.850 GHz
Transmitter Power (EIRP)
2.4 GHz: ≤28.5 dBm (FCC), ≤20 dBm (CE/SRRC/MIC)
5.8 GHz: ≤31.5 dBm (FCC), ≤19 dBm (SRRC), ≤14 dBm (CE)
Communication Bandwidth Max 40 MHz
Live View Mode
Low-Latency mode (810p 100fps/120fps), Latency
<
28 ms
High-Quality mode (810p 50fps/60fps), Latency
<
40 ms
Max Video Bitrate 50 Mbps
Transmission Range 10 km (FCC); 6 km (CE/SRRC/MIC)
Audio Transmission Available
Supported Video Recording
Format
MP4 (Video format: H.264)
Supported Video Playback
Format
MP4, MOV, MKV
(Video format: H.264; Audio format: AAC-LC, AAC-HE, AC-3, MP3)
Operating Temperature Range 0° to 40° C (32° to 104° F)
Power Input
Recommended: DJI FPV Goggles Battery
Third-party batteries: 11.1-25.2 V
Goggles Battery
Capacity 1800 mAh
Voltage Max 9 V
Battery Type LiPo 2S
Energy 18 Wh
Charging Temperature Range 0° to 45° C (32° to 113° F)
Max Charging Power 10 W
Runtime
Approx. 1 hour and 50 minutes (ambient temperature: 25°C, screen
brightness: 6)

dji FPV Specifications

General

Product type	Battery
Compatibility	FPV Drone
Product color	Black
Brand compatibility	DJI
Battery voltage	22.2 V
Battery capacity	2000 mAh
Battery LED indicator	Yes
Minimum operating temperature	5 °C
Quantity per pack	1 pc(s)

Weight and Dimensions

Weight	295 g
