MATRICE 30 SERIES User Manual
Temperature Measurement Method Spot Meter, Area Measurement
Temperature Measurement Range
High Gain Mode: -20° to 150° C (-4° to 302° F)
Low Gain Mode: 0° to 500° C (32° to 932° F)
Temperature Alert Supported
Palette
White Hot/Black Hot/Tint/Iron Red/Hot Iron/Arctic/Medical/
Fulgurite/Rainbow 1/Rainbow 2
FPV Camera
Resolution 1920×1080
DFOV 161°
Frame Rate 30 fps
Laser Module
Wavelength 905 nm
Max Laser Power 3.5 mW
Single Pulse Width 6 ns
Measurement Accuracy
± (0.2 m + D×0.15%)
D is the distance to a vertical surface
Measuring Range 3-1,200 m (0.5×12 m vertical surface with 20% reectivity)
Vision Systems
Obstacle Sensing Range
Forward: 0.6-38 m
Upward/Downward/Backward/Sideward: 0.5-33 m
FOV 65° (H), 50° (V)
Operating Environment Surfaces with clear patterns and adequate lighting (> 15 lux)
Infrared Sensing Systems
Obstacle Sensing Range 0.1-10 m
FOV 30°
Operating Environment Large, diuse, and reective obstacles (reectivity >10%)
TB30 Intelligent Flight Battery
Capacity 5880 mAh
Voltage 26.1 V
Battery Type Li-ion 6S
Energy 131.6 Wh
Net Weight Approx. 685 g
Operating Temperature -20° to 50° C (-4° to 122° F)
Storage Temperature 20° to 30° C (68° to 86° F)
Charging Temperature
-20° to 40° C (-4° to 104° F)
(When the temperature is lower than 10° C (50° F), the self-
heating function will be automatically enabled. Charging in
a low temperature may shorten the lifetime of the battery)
Chemical System LiNiMnCoO2
