MATRICE 30 SERIES User Manual
Mounting the WB37 Intelligent Battery
A WB37 battery (excluded) can be mounted onto the remote controller in the following steps.
1
2
3
1. Push the rear cover release button to the end to open the rear cover.
2. Insert the WB37 battery into the battery compartment and push it to the top. There will be a clicking
sound to indicate the battery is installed rmly.
3. Close the rear cover.
To remove the WB37 battery, press and hold the battery release button and push the battery
downward.
Mounting the Dongle
The USB-C connector in the dongle compartment can be used to connect a USB-C dongle (excluded)
in the following steps.
1. Push the rear cover release button to the end to open the rear cover. Remove the screws to open
the dongle compartment.
2. Insert the dongle into the USB-C connector. Close the dongle compartment.
3. Attach the dongle compartment with the screws. Close the rear cover.
2
1
3
6
7
4
5
