dji MATRICE 30 Series User Manual

3
©
2022 DJI All Rights Reserved.
The operating temperature of this product is -20° to 50° C. It does not meet the standard
operating temperature for military grade application (-55° to 125° C), which is required to
endure greater environmental variability. Operate the product appropriately and only for
applications that it meets the operating temperature range requirements of that grade.
https://www.dji.com/matrice-30/video
Using This Manual
Legends
Important Hints and Tips Reference
Read Before Use
DJI
TM
provides users with tutorial videos and the following documents.
1. In the Box
2. Disclaimer and Safety Guidelines
3. Intelligent Flight Battery Safety Guidelines
4. Quick Start Guide
5. BS30 Intelligent Battery Station User Guide
6. User Manual
It is recommended to watch all the tutorial videos and read the Disclaimer and Safety Guidelines before
using for the rst time. Prepare for your rst ight by reviewing the quick start guide and refer to this
manual for more information.
Downloading DJI Assistant 2 (Enterprise Series)
Download and install DJI ASSISTANT
TM
2 (Enterprise Series) using the link below:
https://www.dji.com/matrice-30/downloads
Tutorial Videos
Go to the address below or scan the QR code to watch the DJI Matrice 30 tutorial videos, which
demonstrate how to use the Matrice 30 safely.

dji MATRICE 30 Series Specifications

General

Max Flight Time	41 minutes
Max Service Ceiling	7000 m
Max Ascent Speed	6 m/s
Max Descent Speed	5 m/s
Ingress Protection Rating	IP55
Max Speed	23 m/s
Operating Temperature Range	-20°C to 50°C (-4°F to 122°F)
Operating Frequency	2.400-2.4835 GHz, 5.725-5.850 GHz
Max Tilt Angle	35°
GNSS	GPS, GLONASS, BeiDou, Galileo
Hovering Accuracy Range (P-mode with GPS)	±0.5 m (Vertical), ±1.5 m (Horizontal)
Operating Temperature (Battery)	-20°C to 50°C (-4°F to 122°F)
Battery Charging Temperature	5° to 40° C (41° to 104° F)
Transmission Range	15 km
