MATRICE 30 SERIES User Manual
Detection Range
Detection Range of the Vision System
The detection range of the vision system is depicted below. Note that aircraft cannot sense obstacles
that are out of the detection range. Fly with caution.
65°65°
50°50°
50°
50°
0.5-33 m
0.5-33 m
0.5-33 m
0.5-33 m
30°
30°
30°
30°
30°
0.1-10 m
0.1-10 m
0.1-10 m
30°
0.1-10 m
65°
65°
65°
65°
65°
65°
65°65°
0.5-33 m
0.5-33 m
0.5-33 m
0.6-38 m
30°
30°
0.1-10 m
30°
0.1-10 m
30°
0.1-10 m
30°
30°
0.1-10 m
30°
50°
50°
65°
50°
0.5-33 m
0.5-33 m
0.5-33 m
0.6-38 m
30°
30°
30°
30°
30°
0.1-10 m
0.1-10 m
0.1-10 m
0.1-10 m
The gray area is the blind spot of the vision system, where the aircraft cannot detect
objects. Fly with caution.
Users can set the braking and warning distances in DJI Pilot 2. The aircraft brakes automatically
when approaching the braking distance. When the aircraft is in the warning distance, DJI Pilot 2 will
display an orange alert in obstacle information. When the aircraft is close to the braking distance, a
red alert will appear in obstacle information.
Detection Range of the Infrared Sensing System
The detection range of the infrared sensors is 0.1 to 10 m (0.33 to 33 ft). Be aware of the blind spot
(marked grey) of the infrared sensing system. The Aircraft cannot detect and avoid obstacles that are
out of the detection range.

dji MATRICE 30 Series Specifications

General

Max Flight Time	41 minutes
Max Service Ceiling	7000 m
Max Ascent Speed	6 m/s
Max Descent Speed	5 m/s
Ingress Protection Rating	IP55
Max Speed	23 m/s
Operating Temperature Range	-20°C to 50°C (-4°F to 122°F)
Operating Frequency	2.400-2.4835 GHz, 5.725-5.850 GHz
Max Tilt Angle	35°
GNSS	GPS, GLONASS, BeiDou, Galileo
Hovering Accuracy Range (P-mode with GPS)	±0.5 m (Vertical), ±1.5 m (Horizontal)
Operating Temperature (Battery)	-20°C to 50°C (-4°F to 122°F)
Battery Charging Temperature	5° to 40° C (41° to 104° F)
Transmission Range	15 km
