MATRICE 30 SERIES User Manual
Infrared Temperature Measurement
Accuracy
[4]
±2°C or ±2% (using the larger value)
Video Resolution
Infrared Image Super-resolution Mode: 1280×1024
Normal Mode: 640×512
Photo Size
Infrared Image Super-resolution Mode: 1280×1024
Normal Mode: 640×512
Pixel Pitch 12 µm
Temperature Measurement Method Spot Meter, Area Measurement
Temperature Measurement Range
High Gain Mode: -20° to 150° C (-4° to 302° F)
Low Gain Mode: 0° to 500° C (32° to 932° F)
Temperature Alert Supported
Palette
White Hot/Black Hot/Tint/Iron Red/Hot Iron/Arctic/Medical/
Fulgurite/Rainbow 1/Rainbow 2
FPV Camera
Resolution 1920×1080
DFOV 161°
Frame Rate 30 fps
Laser Module
Wavelength 905 nm
Max Laser Power 3.5 mW
Single Pulse Width 6 ns
Measurement Accuracy
± (0.2 m + D×0.15%)
D is the distance to a vertical surface
Measuring Range 3-1,200 m (0.5×12 m vertical surface with 20% reectivity)
Safety Regulation Level Class 1M
Accessible Emission Limit (AEL) 304.8 nJ
Reference Aperture
18mm length, 18mm width (20.3mm diameter if equivalent to
circular)
Max Laser Pulse Emission Power
Within 5 Nanoseconds
60.96 W
Vision Systems
Obstacle Sensing Range
Forward: 0.6-38 m
Upward/Downward/Backward/Sideward: 0.5-33 m
FOV 65° (H), 50° (V)
Operating Environment Surfaces with clear patterns and adequate lighting (> 15 lux)
Infrared Sensing Systems
Obstacle Sensing Range 0.1-10 m
FOV 30°
Operating Environment Large, diuse, and reective obstacles (reectivity >10%)
