MATRICE 30 SERIES User Manual
TB30 Intelligent Flight Battery
Capacity 5880 mAh
Voltage 26.1 V
Battery Type Li-ion 6S
Energy 131.6 Wh
Net Weight Approx. 685 g
Operating Temperature -20° to 50° C (-4° to 122° F)
Storage Temperature 20° to 30° C (68° to 86° F)
Charging Temperature
-20° to 40° C (-4° to 104° F)
(When the temperature is lower than 10° C (50° F), the self-
heating function will be automatically enabled. Charging in
a low temperature may shorten the lifetime of the battery)
Chemical System LiNiMnCoO2
Auxiliary Lights
Eective Illumination Distance 5 m
Illumination Type 60 Hz, solid glow
Remote Controller
General
Screen
7.02 inch LCD touchscreen, with a resolution of 1920×1200
pixels, and high brightness of 1200 cd/m
2
Dimensions (antennas folded) 268×162.7×94.3 mm (L×W×H)
Weight
Approx. 1.25 kg (excl. WB37 battery)
Approx. 1.42 kg (incl. WB37 battery)
Internal Battery
Type: Li-ion (6500 mAh @ 7.2 V)
Charge Type: Supports battery station or USB-C charger
maximum rated power 65W (max voltage of 20V)
Charge Time: 2 hours
Chemical System: LiNiCoAIO2
External Battery
(WB37 Intelligent Battery)
Capacity: 4920 mAh
Voltage: 7.6 V
Battery Type: Li-ion
Energy: 37.39 Wh
Chemical System: LiCoO2
Operating Time
[5]
Internal Battery: Approx. 3 hours 18 min
Internal Battery + External Battery: Approx. 6 hours
Ingress Protection Rating
[3]
IP54
GNSS GPS+Galileo+BeiDou
Operating Temperature -20° to 50° C (-4° to 122° F)
O3 Enterprise
Operating Frequency
[1]
2.4000-2.4835 GHz, 5.725-5.850 GHz
