dji PHANTOM 2 VISION - Antenna Orientation; Remote Controller Operation

©2015 DJI. All Rights Reserved. 10 |
3.4 Antenna Orientation
Try to keep the antenna pointing skyward, perpendicular to the ground, in order to achieve the maximum
communication range during flight.
3.5 Remote Controller Operation
Definitions
The ‘stick neutral’ positions and ‘stick released’ mean the control sticks of the remote controller are placed at
the central position.
To ‘move the stick’ means that the stick of remote controller is pushed away from the central position.
Remote Controller
(Mode 2)
Aircraft
（
nose direction
）
Operation details
The throttle stick controls aircraft altitude/elevation.
Push the stick up and the aircraft will rise.
Pull the stick down and the aircraft will descend.
The aircraft will automatically hover and hold its height
if the sticks are centered.
Push the throttle stick above the centered (mid-point)
position to make the aircraft take-off. When flying, we
suggest that you push the throttle stick slowly to
prevent the aircraft from sudden and unexpected
elevation changes.
OFF CAM ON WIFI ON
MICRO S D
The remote controller’s antenna should be
pointing skyward with no obstacles in the way.
Otherwise, the Failsafe function may initialize
prematurely during flight.
The Mobile Device and Range Extender should
not block the antenna.
