©2015 DJI. All Rights Reserved. 62 |
PHANTOM 2 VISION icon in the Finder or using Launchpad.
Installer in DMG format supports only Mac OS X 10.6(Lion) or above.
Usage of PHANTOM 2 VISION Assistant on Mac OS X and Windows are exactly the same. The
Assistant pages appear in other places of this manual are on the Windows for example.
13.2 Using the PHANTOM 2 VISION Assistant on a PC
Start up the PC, power on the PHANTOM 2 VISION, then connect the PHANTOM 2 VISION to the PC
with a Micro-USB cable. DO NOT disconnect until configuration is finished.
Run the PHANTOM 2 VISION Assistant and wait for the PHANTOM 2 VISION to connect to the Assistant.
Observe the indicators on the bottom of the screen. When connected successfully, the connection
indicator is and communication indicator is blinking .
Choose [Basic] or [Advanced] configuration pages.
View and check the current configuration in the [View] page.
