dji PHANTOM 2 VISION - Ground Station GUI

©2015 DJI. All Rights Reserved. 56 |
12.6.1 Ground Station GUI
[1]
[2]
[3] [4] [5] [6]
[7]
[8]
[9]
[10]
[11]
[13]
[14]
[16]
[15]
[12]
[17]
[1] MODE
Modes include
Hover
：
Hovering
Waypoint
：
Mission in progress
GoHome
：
Returning to home point
Take off
：
Taking off
Landing
：
Landing
GPS
：
GPS flight
Atti.
：
Atti. flight
Manual
：
Manual flight
[2] Approximated Flight Mission Distance
Planned mission distance. To achieve optimum battery performance, max mission distance is restricted to
5km (3miles).
[3] Speed
For flight safety concern, only three gears of flight speed are available. Choose from Fast (8m/s), Mid(4m/s)
and Slow (2m/s) for flight speeds. Estimated 10 minutes flight is achievable when the aircraft travels in “Fast”
gear.
[4] Wi-Fi Signal Strength
Wi-Fi signal strength display. Refer to the Basic Use [5] (Page 44) in Camera Page for details
