5 Preparing the Camera
5.1 The built-in camera
[1]
[2]
[3]
[6]
OFF CAM ON WIFI ON
MICRO S D
[4]
[5]
[1]
[2]
[3]
[4]
[5]
[6]
Lens
Camera Power Switch
Micro-SD Card Slot
Camera Status Indicator
Camera Cable
Capture/Record Button
Camera Features
Specifications
Resolution
14 Megapixels
FOV
120°/ 110° / 85°
Sensor size
1/2.3”
Functions
Supports multi-capture, continuous capture and timed capture
Supports HD Recording (1080p30/1080i60)
Supports both RAW and JPEG photo formats
5.2 Main Functions
[1] Lens
For viewing and photographing, with main parameters of f/2.8
，
FOV 120°.
Please remove the lens cover when the camera is in use and replace the cover for storage.
[2] Camera Power Switch (on the back of the camera)
Used to power the camera on and off.
OFF – Powered off.
CAM ON – Power on, Wi-Fi off.
WIFI ON – Power and Wi-Fi are both on. Make sure to switch to ‘WIFI ON’ and the range extender is powered
on if using the DJI VISION App.
