dji PHANTOM 2 VISION - Specifications

©2015 DJI. All Rights Reserved. 70 |
Specifications
Aircraft
Supported Battery
DJI 5200mAh Li-Po Battery
PHANTOM 2 VISION Weight
1160g
Recommend payload
≤
1300g
Maximum payload
1350g
Hovering Accuracy (Ready to Fly)
Vertical: 0.8m; Horizontal: 2.5m
Max Yaw Angular Velocity
200°/s
Max Tilt Angle
35°
Max Ascent / Descent Speed
Ascent: 6m/s; Descent: 2m/s
Max Flight Speed
15m/s (Not Recommended)
Wheelbase
350mm
Tilt Range of the Camera
0
°
- 60
°
Remote Controller
Operating Frequency
5.728 GHz
－
5.85 GHz
Communication Distance (open area)
CE Compliance: 300m; FCC Compliance: 500m
Receiver Sensitivity (1%PER)
-93dBm
Transmitting Power (EIRP)
CE Compliance: 25mW; FCC Compliance: 125mW
Working Current/Voltage
80mA@6V
Battery
4 AA Batteries
Camera
Resolution
14 Megapixels
FOV
120
°
/ 110
°
/ 85
°
Sensor Size
1/2.3”
Functions
Supports multi-capture, continuous capture and timed capture
Supports HD Recording (1080p30,1080i60)
Supports both RAW and JPEG photo formats
Range Extender
Operating Frequency
2412MHz - 2462MHz
Communication Distance (open area)
300m
Transmitting Power
17dBm
Power Consumption
1.5W
DJI VISION App
Supported Mobile Devices
Recommended: iPhone4s, iPhone5, iPhone5s, iPhone5C, iPhone6,
iPhone6 Plus, iPod Touch4, iPod Touch5;
Available but not recommended: iPad3, iPad4, iPad mini.
