dji PHANTOM 4 PRO - Flight Interface Elements

DJI GO App
Phantom 4 Pro / Pro+ User Manual
50
©
2017 DJI All Rights Reserved.
1. System Status
READY TO GO (GPS)
5IJTJDPOJOEJDBUFTBJSDSBGUnJHIUTUBUVTBOEWBSJPVTXBSOJOHNFTTBHFT
2. Obstacles Detection Status
: Red bars are displayed when obstacles are close to the aircraft. Orange bars are
displayed when obstacles are in detection range.
3. Battery Level Indicator
: The battery level indicator provides a dynamic display of the battery level. The colored
zones on the battery level indicator represent the power levels needed to carry out different functions.
4. Flight Mode
5IFUFYUOFYUUPUIJTJDPOJOEJDBUFTUIFDVSSFOUnJHIUNPEF
5BQUPDPOmHVSFUIF.$.BJO$POUSPMMFS4FUUJOHT5IFTFTFUUJOHTBMMPXZPVUPNPEJGZnJHIUMJNJUTBOE
set gain values.
5. Camera Parameters
Displays camera settings parameters and capacity of the Micro SD card.
6. GPS Signal Strength
: Shows the current GPS signal strength. White bars indicate adequate GPS strength.
7. Obstacle Sensing Function Status
: Tap into this button to enable or disable features provided by the Vision System.
8. Remote Controller Signal Strength
: This icon shows the strength of the remote controller signal.
9. HD Video Link Signal Strength
: This icon shows the strength of the HD video downlink connection between the aircraft and the
remote controller.
10. Battery Level
61%
: This icon shows the current battery level.
Tap to view the battery information menu, set the various battery warning thresholds, and view the
battery warning history.
11. Focus/Metering Button
/ : Tap to switch between focus and metering mode. Tap to select object for focusing or
metering.
12. General Settings
5BQUPFOUFSHFOFSBMTFUUJOHNFOVGPSTFUUJOHNFUSJDTFOBCMJOHMJWFTUSFBNEJTQMBZnJHIUSPVUFT
and so on.
