dji PHANTOM 4 PRO - Upgrading the Firmware

Appendix
Phantom 4 Pro / Pro+ User Manual
64
©
2017 DJI All Rights Reserved.
Upgrading the Firmware
Use DJI Assistant 2 or the DJI GO 4 app to upgrade aircraft and Remote Controller.
Upgrading the Aircraft Firmware
Method 1: Using the DJI Assistant 2
1. Power on the aircraft and connect it to a computer with a USB cable.
2. Launch DJI Assistant 2 and login with a DJI account.
3. Select “Phantom 4 Pro/Pro+” and click “Firmware Upgrade” on the left.
 4FMFDUUIFmSNXBSFWFSTJPOSFRVJSFE
 %+*"TTJTUBOUXJMMEPXOMPBEBOEVQHSBEFUIFmSNXBSFBVUPNBUJDBMMZ
 3FTUBSUUIFBJSDSBGUBGUFSUIFmSNXBSFVQHSBEFJTDPNQMFUF
Method 2: Using the DJI GO 4 App
1. Ensure the both the aircraft and the remote controller are powered on and connected.
2. For Phantom 4 Pro, connect the Micro USB port of the aircraft to the mobile device with the USB
OTG cable.
Remote Controller
Operating Frequency
2.400 - 2.483 GHz and 5.725 - 5.825 GHz
Max Transmission Distance
2.400 - 2.483 GHz (Unobstructed, free of interference)
FCC: 4.3 mi (7 km); CE: 2.2 mi (3.5 km); SRRC: 2.5 mi (4 km)
5.725 - 5.825 GHz (Unobstructed, free of interference)
FCC: 4.3 mi (7 km); CE: 1.2 mi (2 km); SRRC: 3.1 mi (5 km)
Operating Temperature
32° to 104° F (0° to 40° C)
Battery
6000 mAh LiPo 2S
Transmitter Power ( EIRP )
2.400 - 2.483 GHz
FCC: 26 dBm; CE: 17 dBm; SRRC: 20 dBm
5.725 - 5.825 GHz
FCC: 28 dBm; CE: 14 dBm; SRRC: 20 dBm
Operating Current/Voltage
1.2 A @7.4 V
Video Output Port
GL300E: HDMI
GL300F: USB
Mobile Device Holder
GL300E: Built-in Display device (5.5 inch screen, 1920×1080,
1000 cd/m
2
, Android system, 4G RAM+16G ROM)
GL300F: Tablets and smartphones
Charger*
Voltage
17.5 V
Rated Power
100 W
Intelligent Flight Battery* (PH4-5870mAh-15.2V)
Capacity
5870 mAh
Voltage
15.2 V
Battery Type
LiPo 4S
Energy
89.2 Wh
Net Weight
468 g
Charging Temperature Range
41° to 104° F (5° to 40° C)
Max. Charging Power
100 W
* Intelligent Flight Batteries and Chargers for Phantom 4 series can be used interchangeably.
