Product Profile

Phantom 4 Pro / Pro+ User Manual

2. Attaching the Propellers

Mount the propellers with black propeller rings to the motors with black dots. Mount the propellers with

sliver propeller rings to the motors without black dots. Press the propeller down onto the mounting plate

and rotate in the lock direction until it is secured.

Preparing the Remote Controller

Tilt the mobile device holder or the display device on the remote controller to the desired position,

then adjust the antennas so they are facing outward.

If using the Phantom 4 Pro, follow the steps below to secure tablet or mobile device to the mobile

device holder.

1. Press the button on the top right side of the mobile device holder to release the clamp, then adjust the

DMBNQUPmUUIFTJ[FPGZPVSNPCJMFEFWJDF

2. Secure your mobile device in the clamp by pressing down, and connect your mobile device to the

remote controller using a USB cable.

3. Plug one end of the cable into the mobile device, and the other end into the USB port on the back of

the remote controller.

.BLFTVSFUIBUZPVIFBSBDMJDLTPVOEJOEJDBUFTUIFCBUUFSZJTmSNMZJOTUBMMFE'BJMVSFUPEPTP

NBZBGGFDUUIFnJHIUTBGFUZPGZPVSBJSDSBGU

3. Battery Installation

Slide battery into the battery compartment according to the arrow’s direction as shown below.

Other manuals for dji PHANTOM 4 PRO

Questions and Answers:

Need help?

Do you have a question about the dji PHANTOM 4 PRO and is the answer not in the manual?

General

Type	Quadcopter
Product color	Grey, White
Maximum speed	6 m/s
Frequency band	2.400 - 2.483 GHz, 5.725 - 5.825 GHz GHz
Number of axis	3
GPS (satellite)	Yes
Number of rotors	4 rotors
Maximum tilt angle	42 °
Maximum flight time	30 min
Maximum descent speed	4 m/s
Maximum weight capacity	- kg
Maximum wind resistance	10 m/s
Vertical hover accuracy	0.1 m
Horizontal hover accuracy	0.3 m
Maximum operating distance	6000 m
Maximum pitch angular velocity	250 °/sec
Battery voltage	15.2 V
Battery capacity	5870 mAh
Transmitter battery capacity	6000 mAh
Megapixel	20 MP
Sensor type	CMOS
Video resolutions	1280 x 720, 1920 x 1080, 2720 x 1530, 3840 x 2160 pixels
Maximum frame rate	30 fps
Optical sensor size	1 \
Camera shutter speed	8 - 1/2000, 8 - 1/8000 s
Image formats supported	DNG, JPG, RAW
Video formats supported	AVC, H.264, H.265, HEVC, MOV, MP4
Maximum video resolution	4096 x 2160 pixels
Field of view (FOV) angle	70 °
Bitrate at maximum video resolution	100 Mbit/s
Operating temperature (T-T)	0 - 40 °C
Built-in processor	-
Operating frequency	2.4 - 2.483 MHz
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	128 GB
Moving control functions	Backward, Downward, Forward
