38
KR
개요
1. 짐벌 커넥터
2. 모터
3. LiDAR
4. RGB 매핑 카메라
5. 보조 포지셔닝 비전 센서
6. microSD 카드 슬롯
7. 틸트 모터
8. 모터
1
3
6
7
8
4
5
2
2.
기체에서
짐벌
카메라
탈부착용
버튼을
누릅니다
.
기체에
있는
짐벌
캡을
돌려
제거합니다
.
3.
짐벌의
흰색
점과
기체의
빨간색
점을
맞춘
짐벌을
삽입합니다
.
4.
짐벌
잠금장치를
빨간색
점에
맞춰
잠금
위치로
돌립니다
.
설치
1. 짐벌 렌즈 보호대를 제거합니다.
2
11
3

Other manuals for dji ZENMUSE L1

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the dji ZENMUSE L1 and is the answer not in the manual?

dji ZENMUSE L1 Specifications

General IconGeneral
Product typeCamera module
CompatibilityMatrice 300 RTK
Product colorBlack
Brand compatibilityDJI
Operating temperature (T-T)-20 - 50 °C
Megapixel20 MP
Sensor typeCMOS
Maximum frame rate30 fps
Camera shutter speed1/8000 - 8 s
ISO sensitivity (max)12800
ISO sensitivity (min)100
Image formats supportedJPEG
Video formats supportedH.264, MOV, MP4
Maximum video resolution3840 x 2160 pixels
Field of view (FOV) angle95 °
Weight and Dimensions IconWeight and Dimensions
Depth169 mm
Width110 mm
Height152 mm
Weight930 g
