61
SMALLT1A10S (I, SI, H)
3 х 7 Аh; Charging current – 1 А. Output
sockets Schuko (IEC, Schuko + IEC,
Hardware).
SMALLT2A0PS (I, SI, H)
w/o batteries; Charging current – 6 А.
Output sockets Schuko (IEC, Schuko + IEC,
Hardware).
SMALLT2A5S (I, SI, H)
4 х 9 Аh; Charging current – 1 А. Output
sockets Schuko (IEC, Schuko + IEC,
Hardware).
SMALLT2A10S (I, SI, H)
6 х 7 Аh; Charging current – 1 А. Output
sockets Schuko (IEC, Schuko + IEC,
Hardware).
SMALLT3A0PS (I, SI, H)
w/o batteries; Charging current – 6 А.
Output sockets Schuko (IEC, Schuko + IEC,
Hardware).
SMALLT3A5S (I, SI, H)
6 х 9 Аh; Charging current – 1 А. Output
sockets Schuko (IEC, Schuko + IEC,
Hardware).
SMALLT3A10S (I, SI, H)
8 х 7 Аh; Charging current – 1 А. Output
sockets Schuko (IEC, Schuko + IEC,
Hardware).
Table 2. Modifications of the UPS
To increase the battery autonomy time, a user has to connect an external
battery cabinet to the UPS; each model of the UPS (depends on the power
rank) corresponds to its own battery cabinet.
Model
Notes
BPSMLT1-36V
Battery cabinet for SMALLT1
BPSMLT2-72V
Battery cabinet for SMALLT2
BPSMLT3-96V
Battery cabinet for SMALLT3
Table 3. Modifications of the battery cabinets
For long backup models it may be necessary to prepare the following cables:
Cable section, mm^2
Model
Input
Output
Battery
Neutral
Ground
SMALLT1
1
1
4
1
1
SMALLT2
1,5
1,5
4
1,5
1,5
SMALLT3
2,5
2,5
4
2,5
2,5
Table 4. Cables sections using with the UPS
