DKS 1838 - RS-232 Using Wireless Point-To-Point Connection - Data Transfer ONLY; Doorking DKS IM Server - Data Transfer ONLY

1838-065-A-9-15
21
RS-232
Terminal
1
2
3
4
5
6
See 2.4.1
1838
Access
Controller
NO additional hardware required. Manage MULTIPLE entry systems in one programming step through DKS IM server.
2.4.6 DoorKing IM Server - Data Transfer ONLY
Wired or
Wireless
Multiple Entry Systems
Phone Company
1838 Access Controller
Your PC
16AC16ACBAT1NO1NC1C2RY2CAZIMC
5VDCIMDSPKRCOMMICPSWCGNDPHONE
Main Terminal
1838 Access Controller
16AC16ACBAT1NO1NC1C2RY2CAZIMC
5VDCIMDSPKRCOMMICPSWCGNDPHONE
Main Terminal
1838 Access Controller
16AC16ACBAT1NO1NC1C2RY2CAZIMC
5VDCIMDSPKRCOMMICPSWCGNDPHONE
Main Terminal
The IM Server is fee based. Visit
http://www.doorking.com/IMServer
for more information.
Cat-5
Cable
Cat-5
Cable
24 VDC
Power
24 VDC
Power
Your PC
Your Router
Wired or
Wireless
SOFTWARE
INSTALLED
Requires TCP/IP Converter Kit (DoorKing P/N 1830-175) and Wireless Adapter Kit (DoorKing P/N 1815-510 - 1 Remote,
P/N 1815-511 - 2 Remotes, P/N 1815-512 - 3 Remotes). Managing to up to THREE 1838s with your PC.
2.4.5 RS-232 using Wireless Point-to-Point Connection - Data Transfer ONLY
1000 ft Max.
Line-of-Sight
Wireless
Remote
Wireless Base
(Administrator)
16AC16ACBAT1NO1NC1C2RY2CAZIMC
5VDCIMDSPKRCOMMICPSWCGNDPHONE
1838 Main Terminal
Telephone line MUST be used to manage
1838s on a single or multiple phone lines.
Third Party
OR
DKS IM Server
DoorKing
TCP/IP Converter
18 VDC
Power
Pwr
DCS-18V
Network
Reload Defaults
RS232 & 485 To Ethernet
Ethernet
10M/100M
A(+) B(-)
RS485
RS232
+
-
DOO RKI N G
®
®
RS-232
SOFT
WARE
INSTALLED
Internet
Unlimited
Connection
Distance
FAST Data
Transfer Rate
Separate phone line is needed if voice communication is desired.
