6005-065-M-12-17
1
6005 SPECIFICATIONS
DoorKing, Inc. reserves the right to make changes in the products described in this manual without notice and without obligation of DoorKing, Inc. to notify any persons
of any such revisions or changes. Additionally, DoorKing, Inc. makes no representations or warranties with respect to this manual. This manual is copyrighted, all rights
reserved. No portion of this manual may be copied, reproduced, translated, or reduced to any electronic medium without prior written consent from DoorKing, Inc.
Top View
Side View
4”
6”
37” Retracted • 53” Extended
Class of Operation Model 6005 - UL 325 Class I
Type of Gate Vehicular Swing Gates Only
Actuator Arm Voltage 24 VDC
Current 3 Amps
Maximum Thrust 300 daN
Max Gate Weight 500 Lbs.
Max Gate Length 14 Feet
Useful Rod Stroke 15.7 inches of travel
Rod Extension Speed .6 in/sec
Operating Temperature -4°F / 131°F
Cycles Per Hour Approx. 25 Per Hour with AC connected (Cycles will vary with battery power ONLY)
Control Box Types • 115 VAC 60 Hz Single Phase Input Power - 24 VDC Output Power to Gate Operators
• 24 Volt Solar Input Power - 24 VDC Output Power to Gate Operators
