OBU Manual
Version 3.0 August 27, 2020 39
6.3 OBU Display Information
Depending on the vehicle’s location, the OBU indicates the relevant information during the trip. The
registration for the corresponding EETS Service will be detected as well as the toll liable parameters.
OBU display information while driving in a booked EETS Service
You can drive after you have checked or entered the relevant vehicle
parameters.
You are driving in a booked Service (here Germany). But you are not liable
to pay toll, e. g. the current gross train weight is below the liable toll
parameter for the corresponding EETS Service.
You are driving in a booked Service (here Belgium) where the vehicle
parameter “number of axles” is not a liable toll parameter. You can
continue your drive.
In some toll services a sound signal is requested by the national toll
charger after passing a toll gantry and a transaction was performed.
You can continue your drive.
The message is displayed if there is no GPS signal reception. If no GPS
signal is received for more than 30 minutes, the LED turns red.
OBU LED and displayed messages while driving outside a booked EETS service
You are driving in a service area, for which the DKV Euro Service EETS
service is not available or the OBU does not recognize the area as a toll
domain, and thus does not perform any toll charging. Please, check if you
must use another On Board Unit / tolling equipment of another service
provider for toll charging.
Shown while driving in a known but unbooked EETS service (*): You are
driving in a toll domain, for which the toll service is not booked or the
booking process is not yet completed (service not activated). Check if the
service should be booked via your Service Partner.
(*) For technical reasons this display is currently also shown when the OBU
is in Italy. The Italian service will be bookable in the future.)
You can have a look on further information on warning messages or on solving certain problems of the OBU in
chapter 7 Troubleshooting.
provided.
Use local toll
or activated.
DEbag t ≥12 2
ABCDEF12 EU5
BEvia t 15.8 -
ABCDEF12 EU5
