9000 Series Installation and Programming Guide | Digital Monitoring Products, Inc. 13
PROGRAM THE PANEL
Note: If you completed the steps in Pair the Keypad, you may skip this section unless
you need to configure device options like Supervision Time.
To access the Programmer menu, reset the panel, press Keypad in the carousel menu,
enter 6653 (PROG), then press CMD.
After completing each of the following steps, press CMD to advance to the next option.
Refer to the panel programming guide as needed.
DEVICE SETUP
Advance to DEVICE SETUP, then press a select area to enter
the setup menu.
Device Number
Set the keypad address at 1-16 for XR550 Series panels or 1-8
for other compatible panels.
Device Name
Press any select area, then enter a name for the wireless
keypad.
DEVICE SETUP
DEVICE SETUP
DEVICE NO: -
DEVICE SETUP
*UNUSED*
