Digital Monitoring Products, Inc | 9000 Series Installation and Programming Guide 34
SN LEV
RED
BLACK
DMP Li-ion Polymer Cell
Model: 9000BAT
Battery Rating: 3.7V 800 mAh
Batch Code: 12-2008
Part Number: BT-0031
Only use specified charger
Do not short circuit
Do not disassemble
Do not expose to high temperatures
Do not incinerate
Dispose of properly
KEY KEY 1 KEY 2 KEY 3
KEY 4 KEY 5 KEY 6 KEY 7
KEY 8 KEY 9 KEY 10 KEY 11
KEY 12 KEY 13 KEY 14 KEY 15
Figure 10: Battery Location and PCB Connection
