CellCom‑LTE
Programming and Installation Guide Digital Monitoring Products
31
Diagnostics Function
The communicator contains a diagnostics function that allows you to test the integrity of the cellular communication,
setup ECP and DSC Passthu, and check panel settings. To use diagnostics, reset the communicator and enter the
diagnostics code 2313 (DIAG).
Communication Status
This option tests the individual components of cellular communication. The selected test will proceed until the first
component failure or until all components have been tested with positive results. The test screen will display after
each component and will be displayed for twoseconds or until CMD has been pressed.
Panel Settings
Press a top row key to access the serial number, model, and firmware version.
Serial Number
This number is the communicator serial number. Reference this number for communicator date‑of‑manufacture and
hardware version. Press any select area to display the serial number.
Model Number
This menu option displays the model number of the communicator.
Firmware Version
This menu option displays the firmware version number of the communicator and date it was released.
Contact ID Recvd
This displays DTMF digits dialed from the burglary control panel.
ECP Setup
Automatically program ECP Passthru settings. This option is only available when KYPD INPUT is set to ECP.
1. Ensure keypad address 20 is programmed into the VISTA panel. Ensure the ECP panel IP address is set as
default. Advance to ECP SETUP and press any select key or area.
2. At ECP SETUP VISTA 128? If the panel is a VISTA 128, select YES. If the panel is a dierent model, select NO.
3. At INST CODE, enter the ECP panel installer code and press CMD.
4. After configuration is finished, the keypad advances to GET ZONES. Press any select key or area.
As the communicator retrieves zones from the ECP panel, the number of zones is displayed and incremented as
ZONE CT (zone count).
DSC Setup
Automatically program DSC Passthru settings. This option is only available when KYPD INPUT is set to DSC.
1. Ensure the DSC panel IP address is set as default. Advance to DSC SETUP and press any select key or area.
2. At INST CODE, enter the DSC panel installer code and press CMD.
3. After configuration is finished, the keypad advances to GET ZONES. Press any select key or area.
4. At INST CODE, enter the DSC panel installer code and press CMD to retrieve zones.
As the communicator retrieves zones from the DSC panel, the number of zones is displayed and incremented as
ZONE CT (zone count).
Press any select key or area to initiate DSC SETUP. At INST CODE, enter the DSC panel installer code and press
CMD. After attempting to program the DSC panel, the menu advances to GET ZONES. Press any select key or area to
retrieve zones from the panel.
Exiting the Diagnostics program
Press CMD until STOP displays. Press any select area. The keypad returns to the status list display.
Cellular Signal Strength (CELL SIGNAL)
Test the cellular signal strength of the nearest carrier tower. Press any select area to display
cell signal strength. The X’s represent the numerical value of the cell signal strength in
‑dBm. The bars represent signal strength 0‑7.
SIGNAL:
▐▐▐▐▐▐▐
