Digital Monitoring Products Wireless Programming Options
2
ZONE INFORMATION
Wireless Programming Options Digital Monitoring Products
3
ZONE INFORMATION
DMP Wireless
For a DMP 1100X Wireless Receiver set the House Code from 1 to 50. See House Code programming in
System Options. Zones 500 through 999 can be programmed as Wireless zones. Set the XR500 Series panel
J23 jumper to X to enable on-board DMP Wireless operation. Briey reset the panel using the J16 jumper
to activate Wireless operation. Refer to the XR500 Series Installation Guide (LT-0681).
For an 1100 Series Key Fob see section 16.11.
For an FA Series Remote Wireless Receiver see section 16.12.
NOTE: All wireless programming is stored in the XR500 Series panel. The 1100X Wireless Receiver obtains
the necessary programming information from the panel each time the receiver powers up, when the
programmer STOP routine is selected or the panel is reset. The receiver memory refresh takes up to 10
seconds to complete depending on the number of wireless zones programmed and the Red LED remains on
during this time. Normal receiver operation is inhibited during the memory refresh period.
16.10
ZONE INFORMATION
WIRELESS? NO YES
Wireless
Select YES to program this zone as a DMP wireless zone. You must program the
wireless House Code prior to adding DMP wireless zones to the system. See House
Code programming in System Options. Default is NO.
16.10.1
TRANSMITTER
SERIAL#: XXXXXXXX
Serial Number Entry
Enter the eight-digit serial number found on the wireless device.
ALREADY IN USE
ZONE NUMBER: XXX
This prompt displays when the serial number is already programmed for another
zone. The programmed zone number displays.
16.10.2
TRANSMITTER
CONTACT:XXXXXXXX
Contact
This option displays if the serial number entered is for an 1101 Universal
Transmitter. Press any top row Select key to choose internal or external
contacts. Default is INT.
TRANSMTR CONTACT
INT EXT
This option displays when programming an 1101 Transmitter. Select INT to use
the internal reed switch contacts. Select EXT to connect an external device to
the 1101 terminal block.
Note: The 1101 Universal Transmitter serial number may be programmed for
two zones provided the Contact type (INT or EXT) is programmed differently for
each zone.
ALREADY IN USE
ZONE NUMBER: XXX
This message displays when the Contact type (INT or EXT) is already
programmed for another zone. The programmed zone number displays.
By allowing both of the Model 1101 Universal Transmitter contacts (INT and
EXT) to be used at the same time, two zones may be programmed from one
transmitter.
For example, program transmitter serial number 01345678 as Zone 521 with an
INT contact type. Then program the same transmitter serial number 01345678
as Zone 522 with an EXT contact type. The same serial number is used for both
zones.
Note: When using both contacts, you must use consecutive zone numbers.
For example, zones 531 and 532 or zones 890 and 891 are acceptable zone
assignments.
ZONE INFORMATION
NORM OPN NO YES
This option only displays when EXT is selected as the Contact type. For external
devices connected to the 1101 terminal block, select NO to use normally closed
(N/C) contacts. Select YES to use normally open (N/O) contacts. Default is NO.
