XR500/XR100 User’s Guide 3Introduction
DMP Keypads
Your system may have one or more easy to use LCD keypads that allow you to properly operate the system.
32-Character Display
Armed LED
Power LED
Data Entry Digit keys
COMMAND Key
Back Arrow Key
Select Keys
1 2 3 4
9 0 CMD
5 6 7 8
ABC PRINTING
FRI 2:51 AM
Backlit Logo
and Proximity
Antenna
Thinline™/Aqualite™ Keypad
AC Power/Armed LED
Three Panic Icons
32-Character
Display with
Four Touch
Select Areas
Data Entry
Digit Keys
COMMAND KeyBack Arrow Key
Logo
Icon
ABC PRINTING
FRI 2:51 AM
Clear Touch™ Keypad
32-Character Display
Data Entry Digit keys
COMMAND Key
Back Arrow Key
Select Keys
Backlit Logo
and Proximity
Antenna
SMITH RESIDENCE
FRI 12:51
PM
Thinline™ Wireless Keypad
