DMXking LeDMX2 MAX - 4. CONFIGURATION UTILITY; Port Tab A (DMX512 Port) Configuration

DMXking.com • JPK Systems Limited • New Zealand
0128-700-4.0
5
Port Tab A (DMX512 port)
Parameter
Default Setting
Async Update Rate
40 [DMX512 frames per second]. Universe Sync will override.
Port Operation Mode
DMX-OUT
Timeout all sources
Unchecked
Channel Offset
0
Fixed IP
0.0.0.0 [Only for DMX IN – Unicast to 1 IP address only]
Merge Mode
HTP
Full DMX Frame
Unchecked
Broadcast Threshold
10 [Art-Net II/3/4 unicasting up to 10 nodes]. Set to 0 for Art-Net I
broadcast on DMX IN ports.
Unicast IP [DMX-IN]
0.0.0.0
sACN Priority [DMX-IN]
100
RDM Discovery Period [DMX-OUT]
0s / RDM Disabled
RDM Packet Spacing [DMX-OUT]
1/20s
DMX-OUT Failsafe Mode
Hold Last
Recall DMX Snapshot at startup
Unchecked
DMX512 Universe
1 [Net 00, Subnet 0, Universe 0]
Note: sACN Universe 1 = Art-Net 00:0:0
4. CONFIGURATION UTILITY
The eDMX Configuration utility provides a simple interface to all device parameters. Typically, these are set once during initial
configuration and left untouched.
eDMX Configuration functions with primary Art-Net UDP 6454 and an alternate UDP 16454 port for device configuration. This is
helpful when simultaneously running eDMX Configuration and a lighting control application. Automatic selection of alternate port
is performed upon utility startup if the primary Art-Net port is unavailable. It is also possible to lock eDMX Configuration to the
alternate port via the Advanced menu. Note that DMXking nodes are always listening on both primary and alternate ports so there
is no device configuration required to change.
