144
STARTING AND OPERATING
POWER ASSISTANCE
ST
ARTING THE ENGIN
E
Battery charge warning lamp (1)
Engine oil level indicator lamp
(2)
W
ARNING!
When the engine is not
running, ther
e is no power
assistance for the brake
and steering system. In
this case, it is importan
t to keep in mind that a
considerably hi
gher degree of effort is necessary
to brake and steer the vehicle.
143
145
