UNDERSTANDING THE FEATUR
ES OF YOUR VEHICLE
77
3
Headlamp Cleaning System (Optional)
The headlamps will be clea
ned with a high-pressure
water jet when
•
the headlamps are switched on
and
•
the windshield wiper
s operate with washer fluid.
NOTE: Fluid for the headlamp
cleaning system is also
supplied from th
e washer system fluid reservoir.
SPEED CONTROL (OPTIONAL)
Set
/
accelerate speed (1)
Set
/
decelerate speed (2)
Off (3)
Resume set speed (4)
76
