THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 15
2
CENTRAL LOCKING (OPTIONAL)
To unlock (1)
To lock (2)
To unlock (1)
To lock (2)
CAUTION!
An unlocked vehicle
is an invitation
to thieves.
Always remove the key fr
om the ignition and lock
all doors when leaving
the vehicle unatt
ended.
W
ARNING!
For personal security and safety in the event of an
accident, lock the vehicl
e doors when you drive
as well as when you pa
rk and leave the vehicle.
