MAINTAINING YOUR VEHICLE 277
7
Fuses, relays and diodes (optional equipment) are
below the driver’s seat, refer to "Optional Fuse and
Relay Equipment".
Standard Fuse and Relay Equipment
Locked (1)
Unlocked (2)
Detent spring – engage when the cover is fitted (3)
CAUTION!
When replacing a blown fuse, it is important to
use only a fuse having the correct amperage
rating. The use of a fuse with a rating other than
indicated may result in a dangerous electrical
system overload. If a properly rated fuse
continues to blow, it indicates a problem in the
circuit that must be corrected.
