240
WHAT TO DO
IN EMERGENCIES
Front Axle Jack Poin
t
(All Vehi
cles)
The vehicle jacking point is located under the
longitudinal member in front of the front axle.
Rear Axle Jack Point for 8,550
lbs (3,880
kgs)
(Vehicle typ
e 2500 HC/SHC)
The vehicle jacking point
is located under the
longitudinal member
in front of the rear a
xle.
CAUTION!
Do not positi
on the jack at
the leaf spring or the
differential housing.
239
241
