22 4445103618
Mounting the charging
booster
Installation location
A
I
Observe the following instructions when selecting
an installation location:
• Ensure that the mounting surface is solid and
level.
• Observe the distance specifications (fig. 4,
page 4).
Using the display panel
The display panel can be mounted depending on
the installation position of the charging booster.
➤To rotate and reinsert the display panel in place
proceed as shown (fig. 6, page 5).
➤To use the display panel as a remote control pro-
ceed as shown (fig. 7, page 5).
Connecting the charging
booster
!
A
I
Observe the following instructions when connect-
ing the charging booster:
• Select the appropriate connection variant.
NOTICE! Damage hazard
Before drilling any holes, ensure that no
electrical cables or other parts of the
vehicle can be damaged by drilling, saw-
ing and filing.
NOTE
The charging booster can be installed in
any mounting position (fig. 5, page 4).
The electrical power supply must be
connected by a qualified electrician who
has demonstrated skill and knowledge
related to the construction and opera-
tion of electrical equipment and installa-
tions and has received safety training to
identify and avoid the hazards involved.
CAUTION! Fire hazard
• Observe the recommended cable
cross-sections, cable lengths and fuses
(see chapter “Determine the cable
cross-section” on page 23).
• Place the fuses near the batteries to
protect the cable from short circuits
and possible burning.
• Ensure that the screws on the terminals
are tightened firmly (torque: 2 Nm
± 0.1). Tighten the screws on the ter-
minals again after mounting the device
and final cable laying.
NOTICE! Damage hazard
Do not reverse the polarity.
NOTE
• In the case of two or more batteries,
parallel connection is permissible if the
batteries are of the same type, capacity
and age. Connect the batteries diago-
nally.
• For LiFePO4 batteries: To ensure mea-
suring the internal temperature of the
battery use the temperature sensor
connector to connect the probe of the
temperature sensor to the negative ter-
minal of the house battery.
