Legend for fig. g, page 8 to fig. k, page 12:
• Always connect the charging booster before
connecting the batteries.
• Do not use ferrules. Strip the cable ends as fol-
lows:
– Signal cable 6 mm (0.75 – 1.5 mm²)
– Charging cable 12 mm
• Determine the cable cross-section (see chapter
“Determine the cable cross-section” on
page 23).
• Connect the probe of the temperature sensor to
the negative terminal of the house battery
(fig. g 1, page 8 to fig. k 1, page 12).
• If the starting battery and the house battery are
not each grounded on the chassis: Connect the
negative terminal of the house battery to the
negative terminal of the starting battery or to
ground (chassis) (fig. g 2, page 8 to fig. k 2,
page 12).
• Protect the positive cable of the house battery
with a fuse
Ι (see chapter “Determine the cable
cross-section” on page 23).
• Protect the positive cable of the starting battery
with a fuse
ΙΙ (see chapter “Determine the cable
cross-section” on page 23).
• Select the charging program suitable for the
type of house battery used (see chapter “Setting
the charging program” on page 26).
Determine the cable cross-section
MT LB 50
MT LB 60
House battery
Starting battery
Cable cross-
section
Cable length
START+
For insulated
assembly:
Cable length
- battery
Cable fuse ΙΙ
Cable length
COM–
to house
battery
Cable length
BORD+
Cable fuse Ι
6mm² – – – 0.5–1.5m 0.5– 1.5m 50A*
10 mm² ≤ 5m ≤ 5 m 80 A 1.0 – 2.5 m 1.0 – 2.5 m 50 A*/60 A
16 mm² ≤ 8m ≤ 8 m 80 A 1.5 – 4.0 m 1.5 – 4.0 m 50 A*/60 A
25 mm² ≤ 11 m ≤ 11 m 80 A 2.5 – 6.0 m 2.5 – 6.0 m 50 A*/60 A
*Setting on “OUT Limit”
Cable cross-
section
Cable length
START+
For insulated
assembly:
Cable length
- battery
Cable fuse ΙΙ
Cable length
COM–
Cable length
BORD+
Cable fuse Ι
10 mm² – – – 0.5 – 2.0 m 0.5 – 2.0 m 70 A
16 mm² ≤ 6m ≤ 6m 100A 1.5–3.5m 1.5–3.5m 70A
25 mm² ≤ 9m ≤ 9m 100A 2.0–5.0m 2.0–5.0m 70A
35 mm² ≤ 12 m ≤ 12m100A–––
