Operation
6.9 Replacing the device fuse
Only CF-35, CF-40, CF-50, CF-60
e
Caution – Danger of electrocution!
Disconnect the connection cable before you replace the device
fuse.
➤ Pull off the connection cable.
➤ Pry out the fuse insert (Fig. 6 2, page 4) with a screwdriver.
➤ Replace the defective fuse with a new one that has the same
rating (T2,5AL 250V).
➤ Press the fuse insert back into the housing.
6.10 Replacing the plug fuse (12/24 V)
➤ Pull the adapter sleeve (Fig. 9 4, page 5) off of the plug.
➤ Unscrew the screw (Fig. 9 5, page 5) out of the upper half of
the housing (Fig. 9 1, page 5).
➤ Carefully raise the upper half of the housing from the lower
(Fig. 9 6, page 5) half.
➤ Take out the contact pin (Fig. 9 3, page 5).
➤ Replace the defective fuse (Fig. 9 2, page 5) with a new one
that has the same rating (8A 32V).
➤ Re-assemble the plug in the reverse order.
_CF-18_60.book Seite 42 Donnerstag, 26. Juli 2007 3:18 15
21
